How to quantum just-in-time compile VQE with Catalyst¶
Published: April 26, 2024. Last updated: November 12, 2024.
Note
Go to the end to download the full example code.
The Variational Quantum Eigensolver (VQE) is a widely used quantum algorithm with applications in quantum chemistry and portfolio optimization problems. It is an application of the Ritz variational principle, where a quantum computer is trained to prepare the ground state of a given molecule.
Here, we will implement the VQE algorithm for the trihydrogen cation H+3 (three hydrogen atoms sharing two electrons) using Catalyst, a quantum just-in-time framework for PennyLane, that allows hybrid quantum-classical workflows to be compiled, optimized, and executed with a significant performance boost.
We will break the implementation into three steps:
-
Finding the molecular Hamiltonian for H+3.
-
Preparing trial ground step (ansatz).
-
Optimizing the circuit to minimize the expectation value of the Hamiltonian.
Simple VQE workflow¶
The VQE algorithm takes a molecular Hamiltonian and a parametrized circuit preparing the trial state of the molecule. The cost function is defined as the expectation value of the Hamiltonian computed in the trial state. With VQE, the lowest energy state of the Hamiltonian can be computed using an iterative optimization of the cost function. In PennyLane, this optimization is performed by a classical optimizer which (in principle) leverages a quantum computer to evaluate the cost function and calculate its gradient at each optimization step.
Step 1: Create the Hamiltonian¶
The first step is to specify the molecule we want to simulate. We can download the H+3 Hamiltonian from the PennyLane Datasets service:
import pennylane as qml
from pennylane import numpy as np
dataset = qml.data.load('qchem', molname="H3+")[0]
H, qubits = dataset.hamiltonian, len(dataset.hamiltonian.wires)
print(f"qubits: {qubits}")
qubits: 6
Step 2: Create the cost function¶
Here, we prepare the initial state of the quantum circuit using the Hartree-Fock state, and then use
the DoubleExcitation template to create our parametrized circuit ansatz.
Finally, we measure the expectation value of our Hamiltonian.
# The Hartree-Fock State
hf = dataset.hf_state
# Define the device, using lightning.qubit device
dev = qml.device("lightning.qubit", wires=qubits)
@qml.qnode(dev, diff_method="adjoint")
def cost(params):
qml.BasisState(hf, wires=range(qubits))
qml.DoubleExcitation(params[0], wires=[0, 1, 2, 3])
qml.DoubleExcitation(params[1], wires=[0, 1, 4, 5])
return qml.expval(H)
Step 3: Optimize the circuit¶
Since we are using AutoGrad, we can use PennyLane’s built-in
GradientDescentOptimizer to optimize the circuit.
init_params = np.array([0.0, 0.0])
opt = qml.GradientDescentOptimizer(stepsize=0.4)
steps = 10
params = init_params
for n in range(10):
params, prev_energy = opt.step_and_cost(cost, params)
print(f"--- Step: {n}, Energy: {cost(params):.8f}")
print(f"Final angle parameters: {params}")
--- Step: 0, Energy: -1.25144067
--- Step: 1, Energy: -1.25750443
--- Step: 2, Energy: -1.26014791
--- Step: 3, Energy: -1.26129611
--- Step: 4, Energy: -1.26179425
--- Step: 5, Energy: -1.26201033
--- Step: 6, Energy: -1.26210406
--- Step: 7, Energy: -1.26214474
--- Step: 8, Energy: -1.26216238
--- Step: 9, Energy: -1.26217005
Final angle parameters: [0.16684898 0.16735496]
Quantum just-in-time compiling VQE¶
To take advantage of quantum just-in-time compilation, we need to modify the above workflow in two ways:
-
Instead of AutoGrad/NumPy, We need to use JAX, a machine learning framework that supports just-in-time compilation.
-
We need to decorate our workflow with the
qjit()decorator, to indicate that we want to quantum just-in-time compile the workflow with Catalyst.
When dealing with more complex workflows, we may also need to update/adjust other aspects, including how we write control flow. For more details, see the Catalyst sharp bits documentation.
Step 2: Create the QJIT-compiled cost function¶
When creating the cost function, we want to make sure that all parameters and arrays are created
using JAX. We can now decorate the cost function with qjit():
from jax import numpy as jnp
hf = np.array(dataset.hf_state)
@qml.qjit
@qml.qnode(dev)
def cost(params):
qml.BasisState.compute_decomposition(hf, wires=range(qubits))
qml.DoubleExcitation(params[0], wires=[0, 1, 2, 3])
qml.DoubleExcitation(params[1], wires=[0, 1, 4, 5])
return qml.expval(H)
init_params = jnp.array([0.0, 0.0])
cost(init_params)
Array(-1.23766738, dtype=float64)
Step 3: Optimize the QJIT-compiled circuit¶
We can now optimize the circuit. Unlike before, we cannot use PennyLane’s built-in optimizers (such
as GradientDescentOptimizer()) here, as they are designed to work with AutoGrad and are
not JAX compatible.
Instead, we can use Optax, a library designed for
optimization using JAX, as well as the value_and_grad() function, which allows us to
differentiate through quantum just-in-time compiled workflows while also returning the cost value.
Here we use value_and_grad() as we want to be able to print out and track our
cost function during execution, but if this is not required the grad() function
can be used instead.
import catalyst
import optax
opt = optax.sgd(learning_rate=0.4)
@qml.qjit
def update_step(i, params, opt_state):
"""Perform a single gradient update step"""
energy, grads = catalyst.value_and_grad(cost)(params)
updates, opt_state = opt.update(grads, opt_state)
params = optax.apply_updates(params, updates)
catalyst.debug.print("Step = {i}, Energy = {energy:.8f} Ha", i=i, energy=energy)
return (params, opt_state)
opt_state = opt.init(init_params)
params = init_params
for i in range(10):
params, opt_state = update_step(i, params, opt_state)
Step = 0, Energy = -1.23766738 Ha
Step = 1, Energy = -1.25144067 Ha
Step = 2, Energy = -1.25750443 Ha
Step = 3, Energy = -1.26014791 Ha
Step = 4, Energy = -1.26129611 Ha
Step = 5, Energy = -1.26179425 Ha
Step = 6, Energy = -1.26201033 Ha
Step = 7, Energy = -1.26210406 Ha
Step = 8, Energy = -1.26214474 Ha
Step = 9, Energy = -1.26216238 Ha
Step 4: QJIT-compile the optimization¶
In the above example, we QJIT-compiled just the optimization update step, as well as the cost function. We can instead rewrite the above so that the entire optimization loop is QJIT-compiled, leading to further performance improvements:
@qml.qjit
def optimization(params):
opt_state = opt.init(params)
(params, opt_state) = qml.for_loop(0, 10, 1)(update_step)(params, opt_state)
return params
final_params = optimization(init_params)
print(f"Final angle parameters: {final_params}")
Step = 0, Energy = -1.23766738 Ha
Step = 1, Energy = -1.25144067 Ha
Step = 2, Energy = -1.25750443 Ha
Step = 3, Energy = -1.26014791 Ha
Step = 4, Energy = -1.26129611 Ha
Step = 5, Energy = -1.26179425 Ha
Step = 6, Energy = -1.26201033 Ha
Step = 7, Energy = -1.26210406 Ha
Step = 8, Energy = -1.26214474 Ha
Step = 9, Energy = -1.26216238 Ha
Final angle parameters: [0.16684898 0.16735496]
Note that here we use the QJIT-compatible for_loop() function, which allows
classical control flow in hybrid quantum-classical workflows to be compiled.
