How to build compressed double-factorized Hamiltonians¶

Constructing the electronic Hamiltonian¶

The Hamiltonian of a molecular system in the second-quantized form can be expressed as a sum of the one-body and two-body terms as follows:

where the tensors $h_{pq}$ and $g_{pqrs}$ are the one- and two-body integrals, $a^\dagger$ and $a$ are the creation and annihilation operators, $\mu$ is the nuclear repulsion energy constant, $\sigma \in {\uparrow, \downarrow}$ represents the spin, and $p, q, r, s$ are the orbital indices. In PennyLane, we can obtain $\mu$, $h_{pq}$ and $g_{pqrs}$ using the electron_integrals() function:

import pennylane as qml

symbols = ["H", "H", "H", "H"]
geometry = qml.math.array([[0., 0., -0.2], [0., 0., -0.1], [0., 0., 0.1], [0., 0., 0.2]])

mol = qml.qchem.Molecule(symbols, geometry)
nuc_core, one_body, two_body = qml.qchem.electron_integrals(mol)()

print(f"One-body and two-body tensor shapes: {one_body.shape}, {two_body.shape}")

One-body and two-body tensor shapes: (4, 4), (4, 4, 4, 4)

In the above expression of $H$, the two-body tensor $g_{pqrs}$ can be rearranged to define $V_{pqrs}$ in the chemist notation, which leads to a one-body offset term $\sum_{s} V_{pssq}$. This allows us to rewrite the Hamiltonian as:

with the transformed one-body terms $T_{pq} = h_{pq} - 0.5 \sum_{s} g_{pqss}$. We can obtain the $V_{pqrs}$ and $T_{pq}$ tensors as:

two_chem = 0.5 * qml.math.swapaxes(two_body, 1, 3)  # V_pqrs
one_chem = one_body - 0.5 * qml.math.einsum("pqss", two_body)  # T_pq

A key feature of this representation is that the modified two-body terms can be factorized into a sum of low-rank terms, which can be used to efficiently simulate the Hamiltonian 2. We will see how to do this with the double-factorization methods in the next section.

Double factorizing the Hamiltonian¶

The double factorization of a Hamiltonian can be described as a Hamiltonian manipulation technique based on decomposing $V_{pqrs}$ into symmetric tensors $L^{(t)}$ called factors, such that $V_{pqrs} = \sum_t^T L_{pq}^{(t)} L_{rs}^{(t) {\dagger}}$ and the rank $T \leq N^2$, where $N$ is the number of orbitals. We can do this by performing an eigenvalue or a pivoted Cholesky decomposition of the modified two-body tensor. Moreover, each of the $L^{(t)}$ can be further eigendecomposed as $L^{(t)}_{pq} = \sum_{i} U_{pi}^{(t)} W_i^{(t)} U_{qi}^{(t)}$ to perform a second tensor factorization. This enables us to express the two-body tensor $V_{pqrs}$ in the following double-factorized form in terms of orthonormal core tensors $Z^{(t)}$ and symmetric leaf tensors $U^{(t)}$ 2:

where $Z_{ij}^{(t)} = W_i^{(t)} W_j^{(t)}$. This decomposition is referred to as the explicit double factorization (XDF) and decreases the number of terms in the qubit basis from $O(N^4)$ to $O(N^3)$, assuming the rank of the second tensor factorization to be $O(N)$. In PennyLane, this can be done using the factorize() function, where one can choose the decomposition method for the first tensor factorization (cholesky), truncate the resulting factors by discarding the ones with individual contributions below a specified threshold (tol_factor), and optionally control the ranks of their second factorization (tol_eigval) as shown below:

factors, _, _ = qml.qchem.factorize(two_chem, cholesky=True, tol_factor=1e-5)
print("Shape of the factors: ", factors.shape)

approx_two_chem = qml.math.tensordot(factors, factors, axes=([0], [0]))
assert qml.math.allclose(approx_two_chem, two_chem, atol=1e-5)

Shape of the factors:  (10, 4, 4)

Performing block-invariant symmetry shift¶

We can further improve the double-factorization by employing the block-invariant symmetry shift (BLISS) technique, which modifies the Hamiltonian’s action on the undesired electron-number subspace 3. It helps decrease the one-norm and the spectral range of the Hamiltonian. In PennyLane, this symmetry shift can be done using the symmetry_shift() function, which returns the symmetry-shifted integral tensors and core constant:

core_shift, one_shift, two_shift = qml.qchem.symmetry_shift(
    nuc_core, one_chem, two_chem, n_elec = mol.n_electrons
) # symmetry-shifted terms of the Hamiltonian

Then we can use these shifted terms to obtain a double-factorized representation of the Hamiltonian that has a lower one-norm than the original one. For instance, we can compare the improvement in the one-norm of the shifted Hamiltonian over the original one by accessing the DoubleFactorization’s lamb attribute:

from pennylane.resource import DoubleFactorization as DF

DF_chem_norm = DF(one_chem, two_chem, chemist_notation=True).lamb
DF_shift_norm =  DF(one_shift, two_shift, chemist_notation=True).lamb
print(f"Decrease in one-norm: {DF_chem_norm - DF_shift_norm}")

Decrease in one-norm: 0.6545729345442108

Compressing the double factorization¶

In many practical scenarios, the double factorization method can be further optimized by performing a numerical tensor-fitting of the decomposed two-body terms to obtain $V^\prime$ such that the approximation error $||V - V^\prime||$ remains below a desired threshold 1. This is referred to as the compressed double factorization (CDF) as it reduces the number of terms in the factorization of the two-body term from $O(N^3)$ to $O(N)$ and achieves lower approximation errors than the truncated XDF. Compression can be done by beginning with $O(N)$ random core and leaf tensors and optimizing them based on the following cost function $\mathcal{L}$ in a greedy manner:

where $|\cdot|_{\text{F}}$ denotes the Frobenius norm, $\rho$ is a constant scaling factor, and $|\cdot|^\gamma$ specifies the optional L1 and L2 regularization that improves the energy variance of the resulting representation. In PennyLane, this compression can be done by using the compressed=True keyword argument in the factorize() function. The regularization term will be included if the regularization keyword argument is set to either "L1" or "L2":

_, two_body_cores, two_body_leaves = qml.qchem.factorize(
    two_shift, tol_factor=1e-2, cholesky=True, compressed=True, regularization="L2"
) # compressed double-factorized shifted two-body terms with "L2" regularization
print(f"Two-body tensors' shape: {two_body_cores.shape, two_body_leaves.shape}")

approx_two_shift = qml.math.einsum(
    "tpk,tqk,tkl,trl,tsl->pqrs",
    two_body_leaves, two_body_leaves, two_body_cores, two_body_leaves, two_body_leaves
) # computing V^\prime and comparing it with V below
assert qml.math.allclose(approx_two_shift, two_shift, atol=1e-2)

Two-body tensors' shape: ((6, 4, 4), (6, 4, 4))

While the previous shape output for the factors (10, 4, 4) meant we had $10$ two-body terms in our factorization, the current shape output (6, 4, 4) indicates that we have $6$ terms. This means that the number of terms in the factorization has decreased almost by half, which is quite significant!

Constructing the double-factorized Hamiltonian¶

We can eigendecompose the one-body tensor to obtain similar orthonormal $U^{(0)}$ and symmetric $Z^{(0)}$ tensors for the one-body term and use the compressed factorization of the two-body term described in the previous section to express the Hamiltonian in the double-factorized form as:

This Hamiltonian can be easily mapped to the qubit basis via Jordan-Wigner transformation (JWT) using $a_p^\dagger a_p = n_p \mapsto 0.5 * (1 - z_p)$, where $n_p$ is the number operator and $z_p$ is the Pauli-Z operation acting on the qubit corresponding to orbital $p$. The mapped form naturally gives rise to a measurement grouping, where the terms within the basis transformation $U^{(i)}$ can be measured simultaneously. These can be obtained with the basis_rotation() function, which performs the double-factorization and JWT automatically.

Another advantage of the double-factorized form is the efficient simulation of the Hamiltonian evolution. Before discussing it in the next section, we note that mapping a two-body term to the qubit basis will result in two additional one-qubit Pauli-Z terms. We can simplify their simulation circuits by accounting for these additional terms directly in the one-body tensor using a correction one_body_extra. We can then decompose the corrected one-body terms into the orthonormal $U^{\prime(0)}$ and symmetric $Z^{\prime(0)}$ tensors instead:

two_core_prime = (qml.math.eye(mol.n_orbitals) * two_body_cores.sum(axis=-1)[:, None, :])
one_body_extra = qml.math.einsum(
    'tpk,tkk,tqk->pq', two_body_leaves, two_core_prime, two_body_leaves
) # one-body correction

# factorize the corrected one-body tensor to obtain the core and leaf tensors
one_body_eigvals, one_body_eigvecs = qml.math.linalg.eigh(one_shift + one_body_extra)
one_body_cores = qml.math.expand_dims(qml.math.diag(one_body_eigvals), axis=0)
one_body_leaves = qml.math.expand_dims(one_body_eigvecs, axis=0)

print(f"One-body tensors' shape: {one_body_cores.shape, one_body_leaves.shape}")

One-body tensors' shape: ((1, 4, 4), (1, 4, 4))

We can now specify the Hamiltonian programmatically in the (compressed) double-factorized form as a dict object with the following three keys: nuc_constant ($\mu$), core_tensors ($\left[ Z^{\prime(0)}, Z^{(t_1)}, \ldots, Z^{(t_T)} \right]$), and leaf_tensors ($\left[ U^{\prime(0)}, U^{(t_1)}, \ldots, U^{(t_T)} \right]$):

cdf_hamiltonian = {
    "nuc_constant": core_shift[0],
    "core_tensors": qml.math.concatenate((one_body_cores, two_body_cores), axis=0),
    "leaf_tensors": qml.math.concatenate((one_body_leaves, two_body_leaves), axis=0),
} # CDF Hamiltonian

Simulating the double-factorized Hamiltonian¶

To simulate the time evolution of the CDF Hamiltonian, we will first need to learn how to apply the unitary operations represented by the exponentiated leaf and core tensors. The former can be done using the BasisRotation operation, which implements the unitary transformation $\exp \left( \sum_{pq}[\log U]_{pq} (a^\dagger_p a_q - a^\dagger_q a_p) \right)$ using the Givens rotation networks that can be efficiently implemented on quantum hardware. The leaf_unitary_rotation function below does this for a leaf tensor:

def leaf_unitary_rotation(leaf, wires):
    """Applies the basis rotation transformation corresponding to the leaf tensor."""
    basis_mat = qml.math.kron(leaf, qml.math.eye(2)) # account for spin
    return qml.BasisRotation(unitary_matrix=basis_mat, wires=wires)

Similarly, the unitary transformation for the core tensors can be applied efficiently via the core_unitary_rotation function defined below. The function uses the RZ and IsingZZ gates for implementing the diagonal and entangling phase rotations for the one- and two-body core tensors, respectively, and GlobalPhase for the corresponding global phases:

import itertools as it

def core_unitary_rotation(core, body_type, wires):
    """Applies the unitary transformation corresponding to the core tensor."""
    ops = []
    if body_type == "one_body":  # implements one-body term
        for wire, cval in enumerate(qml.math.diag(core)):
            for sigma in [0, 1]:
                ops.append(qml.RZ(-cval, wires=2 * wire + sigma))
        ops.append(qml.GlobalPhase(qml.math.sum(core), wires=wires))

    if body_type == "two_body":  # implements two-body term
        for odx1, odx2 in it.product(range(len(wires) // 2), repeat=2):
            cval = core[odx1, odx2] / 4.0
            for sigma, tau in it.product(range(2), repeat=2):
                if odx1 != odx2 or sigma != tau:
                    ops.append(qml.IsingZZ(cval, wires=[2*odx1+sigma, 2*odx2+tau]))
        gphase = 0.5 * qml.math.sum(core) - 0.25 * qml.math.trace(core)
        ops.append(qml.GlobalPhase(-gphase, wires=wires))
    return ops

We can now use these functions to approximate the evolution operator $e^{-iHt}$ for a time $t$ with the Suzuki-Trotter product formula, which uses symmetrized products $S_m$ defined for an order $m \in [1, 2, 4, \ldots, 2k \in \mathbb{N}]$ and repeated multiple times 4. In general, this can be easily implemented for standard non-factorized Hamiltonians using the TrotterProduct operation, which defines these products recursively, leading to an exponential scaling in its complexity with the number of terms in the Hamiltonian and making it inefficient for larger system sizes.

The exponential scaling can be improved to a great extent by working with the compressed double-factorized form of the Hamiltonian as it allows reducing the number of terms in the Hamiltonian from $O(N^4)$ to $O(N)$. While doing this is not directly supported in PennyLane in the form of a template, we can still implement the first-order Trotter step using the following CDFTrotterStep() function that uses the CDF Hamiltonian with the leaf_unitary_rotation and core_unitary_rotation functions defined earlier. We can then use the trotterize() function to implement any higher-order Suzuki-Trotter products.

def CDFTrotterStep(time, cdf_ham, wires):
    """Implements a first-order Trotter step for a CDF Hamiltonian.

    Args:
        time (float): time-step for a Trotter step.
        cdf_ham (dict): dictionary describing the CDF Hamiltonian.
        wires (list): list of integers representing the qubits.
    """
    cores, leaves = cdf_ham["core_tensors"], cdf_ham["leaf_tensors"]
    for bidx, (core, leaf) in enumerate(zip(cores, leaves)):
        # Note: only the first term is one-body, others are two-body
        body_type = "two_body" if bidx else "one_body"
        qml.prod(
            # revert the change-of-basis for leaf tensor
            leaf_unitary_rotation(leaf.conjugate().T, wires),
            # apply the rotation for core tensor scaled by the time-step
            *core_unitary_rotation(time * core, body_type, wires),
            # apply the basis rotation for leaf tensor
            leaf_unitary_rotation(leaf, wires),
        ) # Note: prod applies operations in the reverse order (right-to-left).

We now use this function to simulate the evolution of the $H_4$ Hamiltonian described in the compressed double-factorized form for a given number of steps n_steps and starting from a Hartree-Fock state hf_state with the following circuit that applies a second-order Trotter product:

time, circ_wires = 1.0, range(2 * mol.n_orbitals)
hf_state = qml.qchem.hf_state(electrons=mol.n_electrons, orbitals=len(circ_wires))

@qml.qnode(qml.device("lightning.qubit", wires=circ_wires))
def cdf_circuit(n_steps, order):
    qml.BasisState(hf_state, wires=circ_wires)
    qml.trotterize(CDFTrotterStep, n_steps, order)(time, cdf_hamiltonian, circ_wires)
    qml.GlobalPhase(cdf_hamiltonian["nuc_constant"], wires=circ_wires)
    return qml.state()

circuit_state = cdf_circuit(n_steps=10, order=2)

We now test the accuracy of the Hamiltonian simulation by evolving the Hartree-Fock state analytically ourselves and testing the fidelity of the evolved_state with the circuit_state:

from pennylane.math import fidelity_statevector
from scipy.linalg import expm

# Evolve the state vector |0...0> to the |HF> state of the system
init_state = qml.math.array([1] + [0] * (2**len(circ_wires) - 1))
hf_state_vec = qml.matrix(qml.BasisState(hf_state, wires=circ_wires)) @ init_state

H = qml.qchem.molecular_hamiltonian(mol)[0] # original Hamiltonian
evolved_state = expm(-1j * qml.matrix(H) * time) @ hf_state_vec # e^{-iHt} @ |HF>

print(f"Fidelity of two states: {fidelity_statevector(circuit_state, evolved_state)}")

Fidelity of two states: 0.9979700814294173

As we can see, the fidelity of the evolved state from the circuit is close to $1.0$, which indicates that the evolution of the CDF Hamiltonian sufficiently matches that of the original one.

Conclusion¶

Compressed double-factorized representation for the Hamiltonians serves three key purposes. First, it provides for a more compact representation of the Hamiltonian that can be stored and manipulated easier. Second, it allows more efficient simulations of the Hamiltonian time evolution because the number of terms is reduced quadratically. Third, the compact representation can be further manipulated to reduce the one-norm of the Hamiltonian, which helps reduce the simulation cost when using block encoding or qubitization techniques. Overall, employing CDF-based Hamiltonians for quantum chemistry problems provides a relatively promising path to reducing the complexity of fault-tolerant quantum algorithms.

References¶

1(1,2)

Oumarou Oumarou, Maximilian Scheurer, Robert M. Parrish, Edward G. Hohenstein, and Christian Gogolin, “Accelerating Quantum Computations of Chemistry Through Regularized Compressed Double Factorization”, Quantum 8, 1371, 2024.

2(1,2)

Jeffrey Cohn, Mario Motta, and Robert M. Parrish, “Quantum Filter Diagonalization with Compressed Double-Factorized Hamiltonians”, PRX Quantum 2, 040352, 2021.

3

Ignacio Loaiza, and Artur F. Izmaylov, “Block-Invariant Symmetry Shift: Preprocessing technique for second-quantized Hamiltonians to improve their decompositions to Linear Combination of Unitaries”, arXiv:2304.13772, 2023.

4

Sergiy Zhuk, Niall Robertson, and Sergey Bravyi, “Trotter error bounds and dynamic multi-product formulas for Hamiltonian simulation”, arXiv:2306.12569, 2023.
